Wafer Knife Gate Valve

Home ProductsWafer Knife Gate Valve

Pneumatic Wafer Knife Gate Valve
Pneumatic Wafer Knife Gate Valve
Pneumatic Wafer Knife Gate Valve
Pneumatic Wafer Knife Gate Valve
Pneumatic Wafer Knife Gate Valve
Pneumatic Wafer Knife Gate Valve
Pneumatic Wafer Knife Gate Valve
Pneumatic Wafer Knife Gate Valve
Pneumatic Wafer Knife Gate Valve
Pneumatic Wafer Knife Gate Valve

Pneumatic Wafer Knife Gate Valve

KEBV knife gate valves are available in various designs, one-piece body and two-piece bodies, wafer, lug and flange connection, rising stem and non-rising stem, unidirectional and bidirectional seal, soft seat and metal seat, bonnetless and bonneted designs.

Place of Origin: China
Brand Name: KEBV (OEM available)
Model Number: 1.14
Certification: PED/CE, API6D, ISO9001

Product Description

KEBV knife gate valves are available in various designs, one-piece body and two-piece bodies, wafer, lug and flange connection, rising stem and non-rising stem,

 unidirectional and bidirectional seal, soft seat and metal seat,  bonnetless and bonneted designs.

Technical Specifications of Unidirectional Pneumatic Wafer Knife Gate Valve

Size Range

DN 50~1200mm  NPS 2”-48”(Large diameter on request)

Design Options

Unidirectional or Bidirectional Seal;

Rising Stem

Body Material

GGG40, GGG50, WCB, CF8, CF8M, CF3, CF3M, A890 4A etc.

Knife Material

SS304, SS304L, SS316, SS316L, SAF2205, SAF2507

or other requested

Seat Material

NR：70°C  NBR：80°C    EPDM: 120°C   PTFE: 150°C

Viton/FKM: 180°C   Metal seat: SS304/316+Stellite ≥ 200°C

Applicable Standards

Design & Manufacture: MSS SP-81

Face to Face: MSS SP-81/ EN558-1 Series 20

Flange connection: ASME B 16.5, EN1092-1, BS “D”/”E”

(Other connections on customers’ request)

Test: MSS SP-81

Operation

Options

Double-acting or Single-acting Pneumatic actuator

Applications

Pulp & Paper / Water & Waste Water/Mining/Metallurgy

/Petrochemical /Printing & Dying / Pharmacy/ Beverage& Food
